Direct air heaters

The direct MABRE air heaters are an innovative product with the following plus:



Product information PG - Gas (LPG - Natural) / PD - Diesel

Mabre 100 PD
175 PD
100 PG 175 PG
Thermic  Power   Kcal/h               min-max 43.000 - 86.000 73.100 - 150.500 38.700 - 98.900 73.100 - 150.500
Kw                                                    min-max        50 - 100 85 - 175 45 - 115 85 - 175
Oil Flow Kg/h                                 min-max 4,2 - 8,4 7,09 - 14,6 - -
Natural Gas Flow m3/h               min-max - - 4,500 -10,900 8,390 - 17,270
LPG Flow G30 - G31 Kg/h            min-max - - 3,5 - 8,7 6,65 - 13,7
Output % % 100 100 100 100
Electric motor power Kw AXIAL 0,55 1,10 0,55 1,10
Gas Pressure         Mbar - - 65 65
Air capacity m3/h 8.000 12.000 8.000 12.000
Working voltage V. 230 - 1 230 - 1 230 - 1 230 - 1
Lenght (without burner) mm. 1.550 1.800 1.550 1.800
Width mm. 680 780 680 780
Height mm. 700 950 700 950
Weight kg. 100 160 100 160


Different models on request. Data are merely indicative.
